Kenmore Intuition Vacuum Troubleshooting Guide!

If not connected to a power source, the Kenmore vacuum won’t start. Plug it in and ensure the power button is off.

Also, the vacuum may shut off due to a tripped thermal protector from overheating. To resolve, turn it off, unplug it, and let it cool down.

Moreover, Kenmore Intuition vacuum experiences low suction which may result from clogs in the hose or dirty filters. To fix this, inspect the hose for clogs and wash filters with plain water.

The list doesn’t end here regarding Kenmore Intuition Vacuum troubleshooting. So, hang tight to learn all of the problems along with solutions.

Kenmore Intuition Vacuum Troubleshooting: Problems, Reasons, And Solutions

The Kenmore Intuition Vacuum often encounters problems. Let’s have a look at them in brief.

Problems	Reasons	Solutions
Vacuum cleaner won’t start	Not connected with the power sourceTripped circuit breaker	Ensure proper connectionReplace the circuit breaker
Vacuum cleaner starts but shuts off	Thermal fuse	Reset thermal protector
Vacuume lacks suction	Clogged filtersHole in the hose	Clean the filtersReplace the hose
Vacuum makes high-pitched noise	Obstruction in the nozzleBent fan	Clear the obstruction Replace the fan
Power cord won’t rewind	Twisted or stuck cord	Release the cord

I just snapped a quick picture. Now, it’s time to move towards the reasons and solutions in a comprehensive manner.

Problem 1: Vacuum Cleaner Won’t Start

The most common problem of Kenmore Intuition vacuum doesn’t get started. It can happen due to the reasons below.

Reason 1: Not Connected to Power Source

If a Kenmore vacuum cleaner is not connected to a power source, it will not start because it requires electricity to power the motor. If the vacuum cleaner isn’t connected to a power outlet, it cannot operate the motor and create suction.

Solution:

Track the power cord to its source and confirm that the prongs are correctly inserted into the outlet. If they are not, insert them securely. Prior to plugging it back in, make sure the power button on the vacuum cleaner is set to the “off” position.

Reason 2: Fuse Blown or Circuit Breaker Tripped

A tripped circuit breaker or blown fuse can prevent a Kenmore vacuum cleaner from starting because it disrupts the electrical supply to the vacuum.

If there is an electrical overload or a short circuit in the vacuum cleaner, it can cause the circuit breaker to trip or the fuse to blow.

Solution:

To resolve this, Inspect the service panel for any tripped breakers or blown fuses. If you find a tripped breaker, reset it to the “on” position. In case of a blown fuse, replace it with a new one with the same amperage rating.

Make sure that the vacuum cleaner is plugged in, and before resetting the breaker or changing the fuse. It ensures that the power button on the vacuum cleaner is in the “off” position.

Problem 2: Vacuum Cleaner Starts But Shuts Off

Sometimes, the users of Kenmore Intuition vacuum face the vacuum suddenly shuts off.

This issue can be attributed to several potential causes, and troubleshooting is necessary to pinpoint the exact reason.

Reason: Tripped Thermal Protector

A tripped thermal protector in a Kenmore canister vacuum cleaner can be responsible for the vacuum not starting due to an overheating issue.

Thermal protectors are designed to prevent hot motors from causing damage to the vacuum or posing safety risks.

Solution:

If the vacuum shuts off unexpectedly, follow these steps to resolve this.

Step 1: Turn off the vacuum unplug it to let it cool down and allow the thermal protector to reset.

Step 2: Overheating may occur due to clogs in the dustbin, so check for any obstructions in the airflow.

Step 3: Examine the filters and remove any clogs if necessary.

You can get help from this video.

Problem 3: Vacuum Lacks Suction

It is also important to note that this particular type of vacuum does not produce a lot of suction. The users of Kenmore Intuition vacuum face suction issues very often.

Reason 1: Dirt and Clogging

Especially when those are clogged with dirt and debris, the chances of low suction increase potentially. Also, it can happen due to clogged filters. Debris buildup is also a reason for your Dyson DC33 brush not spinning.

Solution:

If your vacuum hose is not performing optimally, it could be due to an obstruction. Here’s how to address it:

Step 1: Inspect the handle for any clogs and remove them. You can also shake the hose to dislodge any obstructions.

Step 2: For stubborn clogs, you may need to use a long, rigid stick to carefully dislodge the obstruction.

Then, If you’re experiencing reduced suction, it may be due to dirty or clogged filters. Here’s how to address it:

Wash the filter with plain water. Then you can use a gentle brush like an old toothbrush. Finally, Allow it to air dry for 24 hours before reinstalling it.

Reason 2: Crack in the Hose

A hole in the hose of a Kenmore vacuum can significantly impact the suction. The hole disrupts the airflow, preventing the vacuum from generating the necessary suction to clean efficiently.

Solution:

To address this, Examine the hose for any visible holes. If you spot a hole, it’s essential to replace the hose.

Problem 4: Vacuum Makes High-Pitched Noise

The high-pitched noise can be quite irritating, making vacuuming an unpleasant experience.

Reason 1: Blockage in the Nozzle

A partial obstruction in the nozzle of a vacuum can be responsible for the vacuum making a high-pitched noise.

The obstruction can cause turbulent airflow, which can create whistling or high-pitched sounds as the air passes through or around the blockage.

Solution:

Inspect the nozzle attached to the hose for any blockages. Gently shake and flex the hose to dislodge any trapped debris. If necessary, you need to unclog the vacuum hose and clean out the mess.

Reason 2: Damaged Fan

A bent or dented fan can cause a high-pitched noise in the vacuum. When the fan blades are damaged, they may not spin as smoothly as they should, leading to the noise.

Solution:

Fan damage can occur when small, hard objects are vacuumed. For that, there is no DIY method that can be used. You should replace the fan if it is bent or dented.

Problem 5: Power Cord Won’t Rewind

The Power cord not rewinding is another big issue. A power cord not rewinding refers to a situation where the power cord does not retract or rewind back into its storage compartment as it should. The problem can occur due to various reasons.

Reason: Compromised Power Cord

The cord might have gotten twisted or stuck within the device, hindering its smooth retraction. If the cord is compromised, with frays or kinks, it may no longer rewind correctly. Such damage can result from prolonged usage or improper handling.

Solution:

Wipe down the power cord with a damp cloth. Ensure it’s completely dry before reinstalling. If the cord is stuck, manually release it and then rewind it into place. This may require several attempts.

For comprehensive directions, consult this video.

Pro Tip: Use your Kenmore Intuition Vacuum Cleaner if your bed always feels sandy!

Conclusion

Now, you know how to do Kenmore Intuition vacuum troubleshooting.

Most of the issues you can solve yourself at home. Some may require to the necessity of professional assistance. In this case, you should consult with them to get the actual solution.
